Description
The U10004DSU unmonitored double mini magnet adds an independent door status contact, letting the access system track door position across a double leaf opening. Each of its magnets holds up to 600lbs (272Kg) in fail-safe operation, and the aluminium unit accepts a selectable 12~24Vdc input.
Key Features
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Holding force up to 2 x 600lbs (272Kg)
- Electro-less nickel plated armature
- Fail-Safe
- Door status: An independent contact that works separately from the magnet to show door status not lock status
Specification
- Dimensions: 42 × 26 × 500mm (H × W × D)
