Description
Two 1200lbs (544kg) magnets share the FR-A10040's 532mm aluminium housing, making it a monitored option for pairs of doors. Status LEDs in red and green confirm operation, the armature is electro-less nickel plated, voltage is selectable between 12 and 24Vdc, and the unit is fire tested to BS EN1634:1.
Key Features
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Monitored
- Fire tested: BS EN1634:1
- Holding force up to 2 x 1200lbs (544Kg)
- Electro-less nickel plated armature
- Status LED: Red and Green
Specification
- Dimensions: 40 × 67 × 532mm (H × W × D)
