Description
Offering clear visual feedback through red and green status LEDs, the U10002 monitored mini magnet holds up to 600lbs (272Kg) in fail-safe operation. The aluminium housing carries an electro-less nickel plated armature, and the voltage is selectable between 12 and 24Vdc to match the rest of the installation.
Key Features
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Monitored
- Holding force up to 600lbs (272Kg)
- Electro-less nickel plated armature
- Fail-Safe
- Status LED: RED and GREEN
Specification
- Dimensions: 27 × 38 × 228mm (H × W × D)
