Description
Suiting DIN-standard lock-cases in wood or metal framed doors, the GK760 is a monitored electric release with a generous 18mm maximum latch throw. It accepts 12 to 24V AC or DC, offers selectable fail-safe or fail-secure operation, and pairs a zinc alloy body with a stainless steel faceplate and long-life solenoid.
Key Features
- Operating voltage 12~24Vac/Vdc
- Monitored
- Material: Zinc alloy main stand, Stainless Steel faceplate.
- Fail-Safe/Fail-Secure (Selectable)
- Max latch throw 18mm
- Door status output
- For wood or metal frame doors
- Long life solenoid
- Suitable for DIN standard lock-cases
Specification
- Dimensions: 17 × 36.5 × 202mm (H × W × D)
