Description
Fire door installations needing lock feedback are well served by the FR-U10002 monitored mini magnet, which pairs red and green status LEDs with up to 600lbs (272kg) of holding force. FD30 and FD60 rated with a one hour UK fire certificate, it operates fail-safe on selectable 12–24Vdc.
Key Features
- FD30 + FD60 Rated
- Operating voltage 12~24Vdc (Selectable)
- Aluminium housing
- Monitored
- Safety bolts fitted
- Fire tested: BS EN1634:1
- Holding force up to 600lbs (272Kg)
- Electro-less nickel plated armature
- Fail-Safe
- 1 Hour UK fire certificate
- Status LED: Red and Green
Specification
- Dimensions: 27 × 38 × 228mm (H × W × D)
