ARCH2-2-10 – Standard Transom Housing

For horizontal fitting over a two-metre span, the ARCH2-2-10 standard transom housing pairs an aluminium body with a single cut out and a 1200lbs (545kg) holding force. A mounting plate is included, and a DS version supports door status monitoring when used with the A10020M.

Key Features

• 2 meter transom housing
• Standard
• Horizontal fitting
• Aluminium
• Holding force 1200lbs (545Kg)
• One cut out
• Complete with mounting plate
• Housings available with a suffix of ‘DS’ for door status monitoring. (For use with A10020M)

Specification

• Dimensions: 70 × 50 × 2000mm (H × W × D)
